Drawing - 240-series 1988-

🔍 Vergroten
Fitment key
A = CARB B = F.I C = DSL

Parts

# Part Price
2 Volvo Anello di montaggio galleggiante serbatoio carbura Volvo ricambi no 1235324
1235324
Fits: D
1 1 Retaining ring Spårring 3
 20,84 €
3 Volvo Anello guarnizione in gomma galleggiante serbatoio Volvo ricambi no 949276
949276
Fits: D
1 1 0-ring 0-ring 2
 6,99 €
4 943469
943469
Fits: D
1 1 Hose clamp Slangklamma (946709) 2
5 Volvo afdichting Hoes Volvo typeVolvo 240 260 262Volvo 780 : motor type Volvo onderdeel nr 687245
687245
Fits: D
1 1 Sealing sleeve Tätningshylsa 2
 5,50 €
6 Volvo Benzine tank vlotter 240+260 carburateur versie 1979+ tankarmatuur Volvo onderdeel nr 1367254
1367254
Fits: F.I
1 Combined tank unit Tankarmatur 3
 199,79 €
7 Fascetta stringitubo a molla Volvo universal ohne Classic
1321719
Fits: F.I
2 Clamp Klamma 2
 1,96 €
9 Volvo Gruppo galleggiante serbatoio carburante 240+260 m Volvo ricambi no 1367253
1367253
Fits: CARB, DSL
1 Combined tank unit T ankarmatur 3
 75,60 €
10 rubber tube
3514604
Fits: CARB, DSL
X Rubber hose by the meter Gummislang metervara LG 60mm 2
 13,19 €
11 967919
967919
Fits: CARB, DSL
2 Hose clamp Slangklamma (945919) 2
12 Prodotto Volvo Veer, componente Volvo nr 1312388
1312388
Fits: CARB, DSL
1 Spring Fjäder 2
 2,13 €
13 947279
947279
Fits: CARB, DSL
2 Screw Skruv 2
14 Parte Volvo Veer moer, numero di parte Volvo 942866
942866
Fits: CARB, DSL
1 Spring nut Fjädermutter 2
 0,52 €
15 967770
967770
Fits: CARB, DSL
1 Spring nut Fjädermutter 2
16 Volvo Filtro carburante nel serbatoio carburante 240+260 Volvo ricambi no 1274817
1274817
Fits: CARB, DSL
1 Filter Filter 1
 18,14 €
17 Supporto Volvo, pezzo Volvo nr 1312390
1312390
Fits: CARB, DSL
1 Bracket Konsol 4
 4,72 €
18 Volvo Pompa benzina pompa benzina primaria 240+260+740+7 Volvo ricambi no 3507436
3507436
Fits: CARB, DSL
1 Primary pump Förpump (1389721) 1
 0,00 €
19 940121
940121
Fits: CARB, DSL, E
2 Lock washer 2
20 Prodotto Volvo, bullone Volvo, parte nr 1266390
1266390
Fits: CARB, DSL
2 Nut Mutter 2
 0,94 €
22 Fascetta stringitubo a molla Volvo universal ohne Classic
1321719
Fits: CARB, DSL
2 Clamp Klamma 2
 1,96 €
23 Volvo Unità galleggiante per serbatoio di benzina diesel Volvo ricambi no 1367255
1367255
Fits: CARB, D
1 Level sensor Nivågivare 3
 204,97 €
25 Fascetta stringitubo a molla Volvo universal ohne Classic
1321719
Fits: CARB, D
2 Clamp Klamma 2
 1,96 €
