Drawing - 850-series

Click the drawing to enlarge

Fitment key

A = EXC TURBO B = S70N70 TURBO 2WD C = DSL D = AWD E = C70

Parts

#	Part	Price
1	Volvo Kit frizione Volvo 850 (1994+) M56 B5234FT+B5254F+ Volvo ricambi no 271494 271494 Fits: S70N70 TURBO 2WD, DSL, AWD, C70 1 Clutch kit Kopplingssats 2	203,27 €
	Volvo Kit frizione Volvo 850 (1994+) M56 B5234FT+B5254F+ Volvo ricambi no 271494 271494 Fits: EXC TURBO, DSL, AWD 1 1 Clutch kit Kopplingssats 1998 B5204T2 2	203,27 €
2	72314 72314 Fits: EXC TURBO, DSL 1 1 1 Clutch kit Kopplingssats EXC B5204T2 2
	Kit frizione Volvo 850, S70, V70 (-2000) 272218 Fits: EXC TURBO, DSL, AWD, C70 1 Clutch kit Kopplingssats B5234T4 4	245,89 €
	272229 272229 Fits: EXC TURBO, S70N70 TURBO 2WD, AWD, C70 1 Clutch kit Kopplingssats 4
2	9176002 9176002 Fits: DSL, AWD 1 1 1 Driven plate Lamell FOR 271494 2
	9176205 9176205 Fits: EXC TURBO, DSL 1 1 1 Driven plate Lamell FOR 272314 3
	9176188 9176188 Fits: EXC TURBO, S70N70 TURBO 2WD, AWD, C70 1 Driven plate LameH 3
3	Volvo bout vliegwiel 200/700/850/900/S70/V70 Volvo onderdeel nr 959219 959219 6 6 6 6 6 Hex socket screw lnsexskruv 2	0,00 €
4	9181322 9181322 1 1 1 1 1 Control cylinder Manövercylinder 2
5	9181729 9181729 1 1 1 1 1 Snap-on coupling Snabbkoppling 2
6	Cuffia parapolvere, Forcella frizione Volvo C70 (-2005), S40, V40 (-2004), S60 (-2009), S70, V70 (-2000), S80 (-2006), V70 P26 (2001-2007), V70 XC (-2000) 9181326 1 1 1 1 1 Rubber seal Gummitätning 2	10,12 €
7	947542 947542 2 2 2 2 2 Flange screw Flänsskruv 2
8	Volvo Anello di tenuta Cambio manuale Volvo Volvo ricambi no 1381798 1381798 1 1 1 1 1 Sealing ring Tätningsring 2	17,25 €
9	9176473 9176473 Fits: EXC TURBO, S70N70 TURBO 2WD, AWD, C70 1 Clutch pipe Kopplingsrör 4
9a	Volvo O-ring Linea frizione Volvo Volvo ricambi no 9143918 9143918 Fits: EXC TURBO, S70N70 TURBO 2WD, AWD, C70 1 0-ring 0-ring 4	6,62 €
10	9181337 9181337 Fits: EXC TURBO, S70N70 TURBO 2WD, AWD, C70 1 Clutch line Kopplingsledning 3
11	Tubo flessibile frizione Volvo C70 (-2005), S70, V70 (-2000), S70, V70, V70XC (-2000) 9181324 Fits: DSL 1 1 1 1 Clutch line Kopplingsledning 3	168,68 €
11a	Volvo O-ring Linea frizione Volvo Volvo ricambi no 9143918 9143918 Fits: DSL 1 1 1 1 0-ring 0-ring 4	6,62 €
12	Valvola di spurgo, cilindro ricevitore Volvo C70 (-2005), S40, V40 (-2004), S60 (-2009), S70, V70 (-2000), S70, V70, V70XC (-2000), S80 (-2006), V70 P26 (2001-2007), V70 P26, XC70 (2001-2007) Original 9181332 1 1 1 1 1 Adapter Adapter 3	31,84 €
13	Volvo Perno di bloccaggio Tubo frizione Cilindro seconda Volvo ricambi no 9181827 9181827 3 3 3 3 3 Lock brace Låsbygel 3	3,46 €
14	Volvo Tappo in gomma sfiato freno + ingrassatore Volvo ricambi no 656456 656456 1 1 1 1 1 Rubber cap Gummihatt 2	1,17 €
15	Volvo Pompa frizione Volvo V70 - S70 - XC70 - C70 '98- Volvo ricambi no 9181339 9181339 1 1 1 1 1 Master cylinder Huvudcylinder 3	167,70 €
16	945408 945408 1 1 1 1 1 Flange nut Flänsmutter 1998 2
17	973970 973970 1 1 1 1 1 Six point socket screw Sextandhålskruv 1998 2
18	969159 969159 1 1 1 1 1 Safety brace Säkringsbygel 2
20	9176153 9176153 X X X X X Rubber hose Gummislang LG 335mm 3
21	Morsetto per tubo Volvo, parte Volvo nr 976568 976568 2 2 2 2 2 Hose clamp Slangklamma 2	2,13 €
23	946329 946329 2 2 2 2 2 Flange screw Flänsskruv 2
