Drawing - 850-series
Fitment key
A = S.R
B = W/0 S.R
Parts
| # | Part | Price | |
|---|---|---|---|
| 1 |
roof sheet
9152695
Fits: S.R, C, D, E
1 Roof plate Takplåt 6
|
688,46 € | |
|
Piastra del tetto Volvo, pezzo di ricambio Volvo nr 9152710
9152710
Fits: W/0 S.R, C, D, E
1 Roof plate Takplåt 6
|
781,86 € | ||
| 2 |
Volvo voorruit balk Volvo onderdeel nr 6801724
6801724
Fits: C, D, E
1 1 Windscreen member Vindrutebalk 4
|
103,55 € | |
| 3 |
Bordo del tetto Volvo, pezzo di ricambio Volvo nr 9133006
9133006
Fits: S.R, C, D, E
1 Roof arch Takbåge 4
|
73,11 € | |
| 5 |
Barra posteriore del finestrino Volvo, pezzo Volvo nr 9152697
9152697
Fits: C, D, E
1 1 Rear window member Bakrutebalk 4
|
94,45 € | |
| 6 |
9444517
9444517
Fits: C, D, E
1 1 Firewall L.H.D Mellanbräda L.H.D 5
|
||
|
9444518
9444518
Fits: C, D, E
1 1 Firewall R.H.D Mellanbräda R.H.D 5
|
|||
| 7 |
9444601
9444601
Fits: C, D, E
1 1 Crossmember L.H.D Tvärbalk L.H.D 5
|
||
|
9444602
9444602
Fits: C, D, E
1 1 Crossmember R.H.D Tvärbalk R.H.D 5
|
|||
| 8 |
9152677
9152677
Fits: C, D, E
1 1 Rear shelf Hatthylla 5
|
||
| 9 |
9170217
9170217
Fits: C, D, E
1 1 Connecting plate L.H.D Kopplingsplåt L.H.D 4
|
||
|
6817581
6817581
Fits: C, D, E
1 1 Connecting plate R.H.D Kopplingsplåt R.H.D 4
|
|||
|
2000
2000
Edition 2-1998
|
